feat(sts): exchange opaque API keys at /.sts by hash lookup by alukach · Pull Request #235 · source-cooperative/data.source.coop

alukach · 2026-09-25T20:35:53Z

Supersedes #233. Implements the proxy half of API keys as recorded in the revised ADR-013 (#234, stacked on #232). Pairs with source-cooperative/source.coop#580 (into source-cooperative/source.coop#570's branch), which serves the route this calls. Closes #231. Part of source-cooperative/source.coop#491.

What I'm changing

A service account's API key is an opaque sck_ secret, 30 random base62 characters and a six-character CRC-32 checksum of them (ADR-013, #242), that source.coop stores only as a SHA-256 hash. Nothing signs it. /.sts now accepts one as WebIdentityToken and resolves it by asking source.coop:

Body only. A key is read from the POST form body. One in the query string is refused before any lookup with API key must be sent in the request body, not the URL (request id …), because Cloudflare logs request URLs. A JWT in the query string still goes to the STS route as before.
Local checks first. Trim surrounding whitespace, since every hand-made token file ends in a newline, then require exactly sck_ + 36 base62 characters whose last six are the CRC-32 of the thirty before them (IEEE, as zlib computes it, written out in a few lines rather than a crate). Anything else with the sck_ prefix is refused without a lookup.
One lookup, cached. POST {SOURCE_API_URL}/api/v1/service-account-keys/exchanges with {"key_hash"}, authenticated as the proxy itself (sentinel subject urn:source:data-proxy, the one route ADR-005 now lets the proxy call as itself). The route always answers 200: {account_id, key_id, active: true} or {active: false}. Both are cached for 60 seconds, so revocation takes effect within a minute and an unknown key costs one lookup a minute. A non-200 or network failure fails closed as a 500 InternalError, which SDKs retry, and caches nothing.
One refusal for the key, and one for a mangled one. A key that fails its shape or checksum was cut short or mistyped, and reads InvalidIdentityToken: API key is malformed; check that it was copied whole (request id …); the format is public, so this reveals nothing, and it still counts against the rate limit. Unknown, revoked, expired and disabled all read InvalidIdentityToken: API key was not accepted (request id …), with the id also in x-amzn-requestid. The id is in the message because SDKs show the user nothing else. The proxy logs one WARN line per refusal with the reason it knows (malformed, inactive, query_string, rate_limited) plus the key id and an 8-hex hash prefix; source.coop logs which of unknown, revoked, expired or disabled under the same request id.
Minting. Credentials for the named account under the _default role, sealed like every other session, with the same 900s floor, 3600s default and STS_MAX_SESSION_DURATION_SECS cap. RoleArn's account segment is ignored, as for an Ory token. ReadOnly/FullAccess arrive with Add the ReadOnly Role alongside FullAccess #221.
Rate limit. A new KEY_EXCHANGE_LIMIT ratelimit binding, 100 attempts a minute per client IP, in every wrangler config. A client exchanges about once a session, so a cluster behind one NAT stays far under it. A deployment without the binding logs an error and does not refuse traffic.

Decisions to flag

The limit applies to every sck_ attempt, not only cache misses. The cache sits inside the fetch helper, and at 100 a minute per IP the distinction makes no difference to legitimate traffic. ADR-013's wording is updated in docs(adr): revise ADR-013 — API keys are opaque secrets resolved by the platform #234 to match.
No <RequestId> element in the STS error XML. That lives in multistore-sts's build_sts_error_response; the header plus the message cover what SDKs surface, so no upstream change is needed now.
namespace_ids 1001 (production), 1002 (staging) and 1003 (previews) for the ratelimit binding. They only need to be unique within the Cloudflare account.
CodeQL flags key_hash as weak password hashing (src/keys.rs), and it should be dismissed as a false positive. The rule matches on the name: it takes the key for a password. A key is 256 random bits, so a slow hash or salt adds nothing, and the lookup is a key get, so there is no comparison to time. This is how GitHub stores its own tokens, and ADR-013 (docs(adr): revise ADR-013 — API keys are opaque secrets resolved by the platform #234) records it so nobody later "fixes" it to bcrypt. I have not dismissed the alert; that is the repo owner's call.
Security Audit. It failed here because main's lockfile carried a rustls advisory (RUSTSEC-2026-0285). fix(deps): bump rustls to 0.23.45 for RUSTSEC-2026-0285 #238 fixed that on main, and this branch is rebased onto the fix.

How I did it

src/keys.rs (new, wasm-free): parse_api_key, looks_like_api_key, key_hash, KeyStanding, credentials_for.
src/lib.rs: api_key_exchange runs after ApiAuth is built and before the router, and returns None for anything that isn't an sck_ exchange so the STS route handles it unchanged. exchange_api_key does the lookup and minting; key_refusal builds the uniform refusal; finish adds CORS and the request-id headers to a pre-gateway response; within_rate_limit wraps the binding.
src/source_api/auth.rs: PROXY_SELF_SUBJECT, ApiCaller (anonymous, an account, or the proxy), authorization_header_as_self; authorization_header refuses the sentinel so no request can claim it.
src/source_api/cache.rs: get_or_fetch_key_standing; cached_fetch takes a method, an optional JSON body and an ApiCaller. The cache key is {api_url}?key_hash={hash}, so it is a URL, as the Cache API requires, and is scoped to the environment's API.
src/sts.rs: default_role factored out of StsCredentialRegistry::new.
wrangler.toml, wrangler.preview.toml: the binding per environment. README.md: a Bindings table and an API keys section.

From #233 this keeps finish, the shape of api_key_exchange/exchange_api_key, credentials_for and the method argument to cached_fetch. It drops /.keys, minting, self-verification against the proxy's own JWKS, the api_key role, chrono/rsa and the [patch.crates-io] pin on multistore; developmentseed/multistore#147 is not needed.

How to test it

cargo test: all suites, including the new tests/keys.rs (a key's shape, trimming \n and \r\n, rejection of short, long, wrong-case, mistyped, wrong-checksum, non-base62, checksum-less 47-character and JWT tokens, checksum vectors computed independently with Python's zlib (a CRC above 2^31, one with a leading zero), assembled with concat! so scanners don't flag the file, the SHA-256 test vector, and credentials sealed for the account within floor, default and cap). Run by the pre-commit hook, along with cargo clippy --target wasm32-unknown-unknown -- -D warnings and cargo check --target wasm32-unknown-unknown.
pytest tests/test_api_keys.py against wrangler dev and tests/stub_api.py, which gains the exchanges route keyed by the hash of fixed test keys, with a per-hash call counter. Nine tests, all passing locally with wrangler 3.114: a live key exchanges; an unmodified boto3, configured only by AWS_ROLE_ARN, AWS_WEB_IDENTITY_TOKEN_FILE (a file holding the key and a trailing newline) and AWS_ENDPOINT_URL_STS, acquires credentials; the second exchange within 60s never reaches the API; a trailing newline is harmless; unknown and revoked keys get byte-identical refusals apart from the id, and the refusal is cached; a key in the query string is refused without a lookup; malformed keys, including a mistyped one whose checksum fails, are refused without a lookup and with the malformed message; a wrong role is reported as such; an API 500 fails closed and is not cached. test_control_plane.py and test_writes.py still pass; their credentialed tests need CI's GitHub token and were skipped locally. The checksum commits (d6745e0, 30ad22f) were run by CI's Integration Tests job, which exchanges the new-format keys against the worker; it passed on both.
End to end, once source.coop#580 is on a deployment this preview points at: issue a key from a service account's page, save it to a file, then
```
AWS_WEB_IDENTITY_TOKEN_FILE=./key AWS_ROLE_ARN=arn:aws:iam::000000000000:role/_default \
  AWS_ENDPOINT_URL_STS=https://<preview>/.sts AWS_ENDPOINT_URL_S3=https://<preview> AWS_REGION=us-east-1 \
  aws s3 ls s3://<owner>/<product>/
```
Revoke the key and see the next exchange refused within 60s, then quote the printed request id to find the proxy's and source.coop's log lines. Not run here: it needs feat(accounts): opaque API keys resolved by hash, and a working key UI source.coop#580 deployed.

PR Checklist

This PR has no breaking changes. (JWT exchanges at /.sts are unchanged; the new binding is additive.)
I have updated or added new tests to cover the changes in this PR.
This PR affects the Source Cooperative Frontend & API, and I have opened issue/PR feat(accounts): opaque API keys resolved by hash, and a working key UI source.coop#580 to track the change.

Related Issues

Closes #231. Supersedes #233. ADR: #234 (revises ADR-013, amends ADR-005). Route: source-cooperative/source.coop#580, into source-cooperative/source.coop#570. Epic: source-cooperative/source.coop#491.

🤖 Generated with Claude Code

https://claude.ai/code/session_01R1eiTse4416N6uTgAy4Ddd

claude · 2026-09-25T20:36:10Z

Claude finished @alukach's task in 30s —— View job

✅ No blocking issues — safe to merge.

I read the source diff (src/, Cargo.toml, both wrangler configs). I didn't run the tests. origin/main couldn't be fetched, so I diffed against HEAD~3.

Checked and fine

Panics: parse_api_key checks key.len() == 40 before it slices rest[30..], and the alphanumeric check means byte slicing is safe. credentials_for calls clamp(900, max), which panics if max < 900. config.rs:116 already floors that value at 900.
Key handling:
- The key is hashed after trimming.
- Only the hash is sent to the API and cached.
- The log line carries an 8-hex prefix, not the key.
- authorization_header refuses the urn:source:data-proxy subject, so a request can't claim it.
Refusals: a query-string key is refused before any lookup. Non-200 responses fail closed and aren't cached.

Non-blocking notes

Stale PR description: it says keys are sck_ plus 43 base64url characters. The code now has 30 base62 characters plus a 6-character CRC-32 checksum (40 characters in total). Please update the description, and the README if it repeats the old format.
Shared rate-limit bucket: if cf-connecting-ip is missing, every request lands in one "unknown" bucket (src/lib.rs, within_rate_limit). That's fine behind Cloudflare, but it would throttle everyone if the header were ever stripped.
Empty audiences: the key path mints credentials even when auth_audiences is empty, which turns the JWT path off with a 501. Check that this is intended.

Simplify (ponytail)

src/keys.rs checksum: the hand-rolled bitwise CRC-32 could be crc32fast::hash if it's already in the lockfile, or crc32fast could be added. It's about 10 lines, and the test vector covers it, so leave it if you'd rather not add a dependency.
src/keys.rs key_hash: the per-byte format! loop could be hex::encode(Sha256::digest(..)) if hex is already a dependency.
src/source_api/cache.rs: #[allow(clippy::too_many_arguments)] on cached_fetch, now at 8 arguments, suggests a small request-options struct. It's advisory, so skip it unless a third caller appears.
src/lib.rs sts_error_xml: it hand-builds XML for a single 429 and doesn't escape its arguments, though both are constants today. It could be a constant string.
